Glass type:
Various types of glass
Applications:
Various fields
- Technical advantages
- working principle
Technical Advantages
Insulating Glass Line (IG Line)
Fully automatic production line, high degree of automation
Automatic and precise glass positioning system, low friction, and long life
Screw servo precise pressing function, realize precise fine-tuning
Automatic inflation, two/three layers of insulating glass, special-shaped, large and small pieces, etc.
Multi-axis servo linkage, intelligent, fast, and precise fit the super spacer
Automatic sealing, automatic detection of seal depth, automatic correction of corners
Low-E film removal, automatic dust removal system, automatic grinding wheel correction function
Multi-size, multi-specification, multi-pattern aluminum bar automatic bending
Waterjet
Cantilever structure, which can complete the cutting of complex curves in any plane
Integral cutting head, unique process design, no adjustment
High-quality high-speed supercharger, ultra-high pressure pipeline, cutting efficiency increased by more than 30%
A new generation of high-performance water jet CNC system, servo control system
High-quality backlash-free ball screw to ensure transmission accuracy, durability and high quality
CNC auxiliary functions for automatic control of abrasive supply
New stainless steel labyrinth protection, fully enclosed water jet design
Glass Double Edging Machine
All grinding wheels are automatically adjusted without manual labor
Servo motor control, precision screw structure
High-speed edging, the production capacity is 2.5 times that of the traditional double edging machine
Parallelism error: ≤0.2mm/m
Fast grinding speed, high polishing, low E film removal
Polishing uses a pneumatic compensation device to make the product bright and consistent
Automatic detection of glass size, automatic correction, automatic matching
Scan labels function, remote control, fully automatic production
Glass Shaped Edging Machine
Suitable for round, oval, and other irregular glass shapes
Grinding and polishing of the formed edges and beveled edges
Grinding and polishing of round edges, semi-circular edges, flat edges, etc.
The angle of the grinding wheel and the grinding head is precisely adjusted, the equipment is reliable and durable
The grinding and polishing of the bevel is with high brightness, and the bevel angle can reach 45°
Glass Film Apply Machine
The film has high flatness, no bubbles, no wrinkles
Available with explosion-proof film, protective film and other films, single layer, the double-layer film
Dust removal device to avoid secondary dust contamination of glass
Self-adaptive film roll tension, adjustable torque
Optional functions such as auxiliary flip, splicing combined film, longitudinal cutting, etc.
High-quality explosion-proof film for shower doors glass
Glass Bending Furnace
Intermittent bending, continuous bending
The glass has excellent optical properties and a uniform spherical surface
Advanced heating control, matrix lifting and lowering in the forming section, infrared temperature measurement
Advanced control technology produces all kinds of automotive glass, high-speed rail, and bending glass
Excellent match between mold and glass, mold with extremely low expansion coefficient and thermal conductivity
Fine-tuning mechanism to ensure smooth, accurate, and reliable movement
With glass edge strengthening function, the glass is fully cooled and annealed
Water Treatment Equipment
Water quality has been significantly improved, and water can be recycled for production
Achieve continuous clean water supply for 24 hours a day
An integrated system can replace multi-stage circulating sedimentation tanks or ultra-high vertical flow tanks
Fast separation of flocs and water in the high turbidity sewage purifier
Save cleaning time and labor, effectively extending the service life of the machine
No scratches on the glass surface, avoiding the internal structure of the machine from being corroded by glass powder
The smallest amount of chemical precipitant used, the best combination of water treatment chemicals
Glass Belt Sanding Machine
The equipment parts are sturdy and durable, with a long service life
Adopt a pneumatic flexible tension belt
Fast grinding, especially suitable for door and window glass
The size of the machine and work platform can be customized, suitable for different sizes of glass
Universal wheels use high-quality polyurethane materials with rolling bearings
Flexible rotation of wheels to ensure that the glass will not be scratched and has a long life
A pneumatic control valve can quickly change the sanding belt
Glass Suction Cup Machine (Vacuum Lifter)
High vacuum, reliable suction, guarantee high safety, no air leakage
4 times safety factor, multi-layer safety protection, heavy load
Vacuum filter filters impurities and particles in the air
Patented design, quick suction and release
The suction cup machine can be flipped by 90 degrees and rotated by 360 degrees
The edge design of the suction cup ensures the reliability of the seal
The buffer space ensures that each suction cup is in contact with the glass, and the force is evenly distributed
Glass Sandblasting Machine
High-quality glass sandblasted surface
Touch screen and PLC control, easy to operate
With automatic and manual functions
Special material nozzle, unique design, long service life
High-quality synchronous belt transmission, stable and durable transmission
Automatic dust collection, dust-proof cleaning of the filter bag, reverse blowing mode
Sand proof design for input and output conveyor belts
Automatic Glass Moving and Handling System
Glass conveyor roller table
Industrial robot glass automatic handling
Glass loading and unloading machine, turnover table, tilt table
Automatic glass loading and unloading manipulator, robotic arm
A variety of glass moving, handling, and connection systems are customized according to user needs
Significantly improve the degree of automation and safety
Straight-Line Edging Production Line
Fully automatic turning, flipping, edging, and washing
Suitable for grinding and polishing straight edges and 45° chamfers of flat glass
The four edges of the glass are fully automatically edging without manual labor
Rough grinding, fine grinding, and polishing can be finished in one time
The inlet and outlet guide rails adopt high-quality synchronous belts or conveying chain links, and the glass conveys smoothly
Optional automatic measurement of glass thickness and size, digital display
Shower Door Glass Automatic Production Line
Horizontal drilling + milling, double processing head
Simultaneous milling and grinding, cutouts, and drilling can be completed automatically with high quality
Reduce the transfer of the glass between stations, saving manpower
Avoid repeated manual positioning and reduce time waste
Can cooperate with ERP enterprise software, automatic label scanning, network control
Whole Plant Solutions for Glass Processing Enterprises
Help customers customize a full set of whole plant equipment from edging, washing to tempering
According to different customer needs, customize the most optimized and reasonable plant solution
Create actual value for users through leading technology and high-quality equipment, and improve production efficiency
A complete set of glass machinery selection plan, demand analysis
Consider key issues, control details, and maximize user benefits
Plant Layout Design, Process Flow Design
Plant equipment layout design, floor plan design
Glass processing flow design, production line design
Plant water, electricity, and compressed air demand analysis
Optimize the production process to improve productivity and efficiency
Reduce labor costs and production costs
Maximize corporate profits
